PUSH PULL CONTROL CABLES FOR BUS AND TRUCKS

Product Description

Push-pull cable outer casing is the main part of control cable which can be widely used for
vehicles, construction machinery, and ship industry. It has the property of not being burn-in, no cracking, high&low temperature resistance, friction resistance, corrosion resistance, and long service life.
Raw materials:

Outer surface: PE/PP

Middle: high carbon steel

Inner hole: PE/POM/PTFE

we also can make any specail size as custmer request.

delivery date: 15-25days/20ft.

Specification
  mm

Inner Dia.
  mm

Liner Material

Coating Material

φ4.0

1.5

PP/PE/POM/PTFE

PE/ PP

φ4.15

1.6/1.8

PP/PE/POM/PTFE

PE/ PP

φ5.0

2

PP/PE/POM/PTFE

PE/ PP

φ6.0

2.1

PP/PE/POM/PTFE

PE/ PP

φ7.0

2.3

PP/PE/POM/PTFE

PE/ PP

φ8.2

2.7

PP/PE/POM/PTFE

PE/ PP

φ9.0

3.5/3.8

PP/PE/POM/PTFE

PE/ PP

φ9.0

4.1/4.2

PP/PE/POM/PTFE

PE/ PP

φ10.0

3.8/4.2

PP/PE/POM/PTFE

PE/ PP

φ11.0

4.5/4.8

PP/PE/POM/PTFE

PE/ PP

φ11.0

5.0/5.2

PP/PE/POM/PTFE

PE/ PP

φ12.0

5.5

PP/PE/POM/PTFE

PE/ PP
